LP-21700 Cell Datasheet
Product Overview
LP-21700 is a high-performance lithium-ion cell using advanced lithium iron phosphate technology, suitable for energy storage systems and power bank applications.
Key Features
- Capacity: 5000mAh
- Nominal Voltage: 3.2V
- Cycle Life: ≥4000 cycles (80% DOD)
- Operating Temperature: -20°C ~ 60°C
Technical Specifications
| Parameter | Value |
|---|---|
| Capacity | 5000mAh |
| Nominal Voltage | 3.2V |
| Charge Voltage | 3.65V |
| Discharge Voltage | 2.5V |
| Max Charge Current | 1C (5A) |
| Max Discharge Current | 2C (10A) |
| Internal Resistance | ≤20mΩ |
| Weight | Approx. 75g |
| Dimensions | 21mm diameter, 70mm height |
Applications
- Energy Storage Systems (ESS)
- Home Energy Storage
- Power Banks
- Power Tools
- Backup Power
Safety Precautions
- Avoid overcharge and overdischarge
- Prevent short circuits
- Do not expose to fire
- Use in well-ventilated areas
- Use only dedicated chargers
